SecureNAS® CX-160KSSD-X
Details
Ruggedized Portable Systems. Encrypted FIPS 140-2 level 3 validation
Supporting sixteen hot-swappable 3.5″ SSDs and two mirrored internal SSDs for OS hosting, SecureNAS CX-160KSSD-X is a high capacity, rugged and reliable enterprise NAS powered by an Intel® Xeon® D processor. Built-in Intel® AES-NI provides integrated support to enable a wide range of cryptographic applications, such as bulk encryption/decryption, random number generation, and authenticated encryption, for robust security and reduced latency. Designed to optimize IT infrastructure, CX-160KSSD-X includes two PCIe expansion slots that support additional 10GbE to 40GbE NICs, PCIe SSDs and graphic cards. This 16-bay NAS is capable of serving up to hundreds of gigabytes of data per second while delivering the highest performance with unlimited scalability and enterprise reliability. The SecureNAS deploys large-capacity storage all-flash. The combination of both hardware and CiphertexOS delivers the ideal price/performance ratio required for all-flash workloads in life sciences, semiconductor design, manufacturing, financial services, media & entertainment, academia and government. SecureNAS technology makes it possible for organizations to finally adopt an all-flash system for their data backup and recovery requirements.
SecureNAS technology takes the complexity out of tiered high-performance storage systems by maximizing the efficiency
Flash storage in a SecureNAS platform delivering a simplified experience for infrastructure and data management. A platform that’s easy to set up, easy to change, and easy to enhance in moments, not months. Business-ready storage solution. Featuring Ciphertex’s all-in-one storage management platform with cross-platform file share, automatic backup, Rsync, iSCSI, virtual machine hosting, and ZFS RAIDZ resiliency.
ZFS RAIDZ levels: Mirror, Stripe Set, RAIDZ, RAIDZ2, and RAIDZ3
The SecureNAS’s rugged enclosure ensures durability and protection in all environments. For additional security, the CX-160KSSD-X comes with any requested number of FIPS 140-2 (Level 3) validated Physical Encryption Keys (once installed, the device’s volumes are only accessible when the key is inserted).
| Capacity | Part Number | Price |
| 60TB | SNCX-160KSSD-X-4C-32G-60TB | Call for Price |
| 120TB | SNCX-160KSSD-X-4C-32G-120TB | Call for Price |
| 240TB | SNCX-160KSSD-X-4C-32G-240TB | Call for Price |
| 480TB | SNCX-160KSSD-X-4C-32G-480TB | Call for Price |
Contact a CIPHERTEX sales representative for pricing and
additional information on custom configurations, expansions
and accessories.
Hardware Specs
DRIVE BAYS
16 hot swap 2.5” SSDs and 2 internal SSDs – Up to 480TB storage capacity
PERFORMANCE CPU
Intel® Xeon Processor D-1518 Socket FCBGA 1667 supported CPU TDP support 35W
CORES/CACHE
4 Cores (upgradable to 8 and 16 Cores), 8 Threads /6MB Cache
MEMORY CAPACITY
Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4- 2133MHz, in 4 DIMM slots
MEMORY TYPE
2133/1866/1600MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM
DIMM SIZES
4GB, 8GB, 16GB, 32GB
MEMORY VOLTAGE
1.2V
ERROR DETECTION
Corrects single-bit errors Detects double-bit errors (using ECC memory)
M.2 EXPANSION
M.2 Interface: 1 SATA/PCI-E 3.0 x4
SAS2
Broadcom 2116 SW controller for 16 SATA3 (6Gpbs) ports; SAS2 and SATA3
IPMI
Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM- over-LAN support
NETWORK CONTROLLERS
Dual LAN with 10G SFP+ from D-1500 SoC; Dual LAN with 1GbE w/Intel® I210
GRAPHICS
Aspeed AST2400 BMC
LED INDICATORS
Status/Power, USB, LAN
PUSH BUTTONS
Power, Reset, Copy
TEMPERATURE
0 – 60 ̊C (32 ̊F ~ 140 ̊F)
SMART FAN
1 x 12cm (12V DC)
WEIGHT
32 lbs (w/o drives); Approx. 39 lbs (with SSD drives)
SIZE
Height: Height: 15.25” (387.35 mm) Width: 11.25” (285.75 mm) Depth: 10.5” (266.75 mm)
Features
- Dual 10GbE fibre & copper expandability for highly efficient virtualization and intensive data transmission
- LCD display for real-time information and easier system management
- Smart cooling fan detects internal component temperatures to automatically adjust its speed, delivering the quietest possible operation under various conditions.
- Top-of-the-line hardware for maximum reliability and performance.
- Hardware Encryption Key FIBs 140-2 Level 3
- Accelerated AES-256 bit encryption powered by Intel AES-NI
- Built-in M.2 SATA 6GB/s slot for ultra-high speed performance while taking advantage of SSD caching.
- Centralized management solution for networked computing devices
- Supports centralized storage, backup, sharing, and disaster recovery
- Optional Extended 5-Year warranty (Standard 3-Year)
Accessories
| Type | Ciphertex Part No. | Description |
|---|---|---|
| SSD | SNSSD01TB | 1TB CAPACITY SSD DRIVE |
| SNSSD02TB | 2TB CAPACITY SSD DRIVE | |
| SNSSD04TB | 4TB CAPACITY SSD DRIVE | |
| SNSSD08TB | 8TB CAPACITY SSD DRIVE | |
| SNSSD15TB | 15TB CAPACITY SSD DRIVE | |
| SNSSD30TB | 30TB CAPACITY SSD DRIVE | |
| Network Adapter | 00510G004 | 10G COPPER NETWORK ADAPTER CARD 2 PORTS |
| 00510G014 | 10G COPPER NETWORK ADAPTER CARD 4 PORTS | |
| 00510G040 | 40G FIBER NETWORK ADAPTER CARD | |
| 00510G100 | 100G FIBER NETWORK ADAPTER CARD | |
| SN4PCI | 4 PORT USB 3.0 PCIe EXPANSION CARD | |
| SFT+ Transceiver | 00510G011 | 10GBASE-SR SFP+ TRANSCEIVER |
| Encrpytion Key | SNCPKEY | CIPHERTEX-PROTECT ENCRYPTION KEY |
| Door Lock Key | SNKEY | SECURENAS DOOR LOCK KEY |
| Copper Network Cable | SNNC6A | COPPER NETWORK CABLE |
| Quick Link Cable | SNQL | QUICKLINK CABLE |
| Fiber Network Cable | N.A. | FIBER NETWORK CABLE |
| Transport Case | N.A. | SECURENAS CX-40KHD/SSD HARD TRANSPORT CASE |
| N.A. | SECURENAS CX-80KHD/SSD HARD TRANSPORT CASE | |
| N.A. | SECURENAS CX-120 HARD TRANSPORT CASE | |
| N.A. | SECURENAS CX-160KHD/SSD HARD TRANSPORT CASE |
SSD
2 redundant SSDs for caching and hosting the CiphertexOS.
Memory DDR
32-128 DDR4 ECC memory detects and corrects single-bit memory errors, demonstrating high reliability for crucial applications.
Design
Incredibly solid and rugged design delivers complete physical security during transport.
App. Performance
Two PCIe slots allow for 5GbE/10GbE/25GbE/40GbE NICs, M.2 SSDs, or graphics cards to increase application performance.
Flexible Solutions
Scalable storage supporting virtual machines, containerized apps, centralized storage, backup, sharing, and disaster recovery.
Secure Data
SecureNAS empowers your business. Sleep well knowing your data is totally safe and secure.
Expansion Interface Cards
The additional expansion slots give you the ability to customize your NAS to meet your business's requirements. These are five most popular upgrades:
- 10GB Network Card / Dual Port RJ45
- 40GB Network Card / QSFP
- USB 3.0 PCIE Card / 4 Port
- 10GB Network Card / 4 Port RJ45
- 100GB Network Card / Dual Port QSFP28
- Airtight, Watertight, Rustproof, Shockproof, And Crush Proof
- Impervious to the Rigors of Mother Nature
- Chemical Resistant and Corrosion Proof
- Customizable Durable Foam That Lasts 15 Years
- Automatic Pressure Equalization Valve
- O-Ring Seal
- Stainless Steel Hasp Protectors
- Wheels with Stainless Steel Bearings
- Retractable Extension Handle and Fold Down Handles
- Pockets for Accessories and cables
- Optional Humidity Indicator Plug
Ciphertex Delivers Peace of Mind
with Every SecureNAS®
Ciphertex is proud to lead the Data Security Industry by offering up to a 5-Year Warranty on all models of our SecureNAS® server product line,
starting with a standard 3-Year Warranty.
Parts and factory labor are fully covered, along with unlimited technical support and return ground shipping from our facility. Field service
warranties at various response levels are optionally available.
