SecureNAS® CX-160KHD-X

cx-160khd-x-front-product-display-portable-nas-hard-drive-ciphertex-data-storage-los-angeles-county cx-160khd-x-front-angled-right-product-display-portable-nas-hard-drive-ciphertex-data-storage-los-angeles-county cx-160khd-x-front-open-angled-right-product-display-portable-nas-hard-drive-ciphertex-data-storage-los-angeles-county cx-160khd-x-back-angled-left-product-display-portable-nas-hard-drive-ciphertex-data-storage-los-angeles-county cx-160khd-x-back-product-display-portable-nas-hard-drive-ciphertex-data-storage-los-angeles-county


Hardware Specs



Class-Leading Throughput with Tiered Storage and a Large Encrypted Capacity (64TB – 352TB)
Supporting sixteen hot-swappable 3.5″ HDDs and two mirrored internal SSDs for OS hosting, SecureNAS CX-160KHD-X is a high capacity, rugged, and reliable enterprise NAS powered by an Intel® Xeon® D processor. Built-in Intel® AES-NI provides integrated support to enable a wide range of cryptographic applications, such as bulk encryption/decryption, random number generation, and authenticated encryption, for robust security and reduced latency. Designed to optimize IT infrastructure, CX-160KHD-X includes two PCIe expansion slots that support additional additional 10GbE to 40GbE NICs, PCIe SSDs and graphic cards. This 16-bay NAS is an ideal choice for a scalable, business-ready storage solution. Featuring Ciphertex’s all-in-one storage management platform with cross-platform file share, automatic backup, Office 365 backup, Rsync, iSCSI, virtual machine hosting, and ZFS RAIDZ resiliency.


ZFS RAIDZ levels: Mirror, Stripe Set, RAIDZ, RAIDZ2, and RAIDZ3


The SecureNAS’s rugged enclosure ensures durability and protection in all environments. For additional security, the CX-160KHD-X comes with any requested number of FIPS 140-2 (Level 3) validated Physical Encryption Keys (once installed, the device’s volumes are only accessible when the key is inserted).



2 redundant SSDs for caching and hosting the CiphertexOS.


Memory DDR

32-128 DDR4 ECC memory detects and corrects single-bit memory errors, demonstrating high reliability for crucial applications.



Incredibly solid and rugged design delivers complete physical security during transport.


App. Performance

Two PCIe slots allow for 5GbE/10GbE/25GbE/40GbE NICs, M.2 SSDs, or graphics cards to increase application performance.


Flexible Solutions

Scalable storage supporting virtual machines, containerized apps, centralized storage, backup, sharing, and disaster recovery.


Secure Data

SecureNAS empowers your business. Sleep well knowing your data is totally safe and secure.


Expansion Interface Cards

The additional expansion slots give you the ability to customize your NAS to meet your business's requirements. These are five most popular upgrades:

  • 10GB Network Card / Dual Port RJ45
  • 40GB Network Card / QSFP
  • USB 3.0 PCIE Card / 4 Port
  • 10GB Network Card / 4 Port RJ45
  • 100GB Network Card / Dual Port QSFP28
  • Airtight, Watertight, Rustproof, Shockproof, And Crush Proof
  • Impervious to the Rigors of Mother Nature
  • Chemical Resistant and Corrosion Proof
  • Customizable Durable Foam That Lasts 15 Years
  • Automatic Pressure Equalization Valve
  • O-Ring Seal
  • Stainless Steel Hasp Protectors
  • Wheels with Stainless Steel Bearings
  • Retractable Extension Handle and Fold Down Handles
  • Pockets for Accessories and cables
  • Optional Humidity Indicator Plug

Ciphertex Delivers Peace of Mind
with Every SecureNAS®

Ciphertex is proud to lead the Data Security Industry by offering up to a 5-Year Warranty on all models of our SecureNAS® server product line,
starting with a standard 3-Year Warranty.

Parts and factory labor are fully covered, along with unlimited technical support and return ground shipping from our facility. Field service
warranties at various response levels are optionally available.
